Элеваторы с центральным затвором для захвата под замок, ТИП "ТА", ТИП "RA"
| ДИАМЕТР
ТРУБЫ, ММ |
ОБОЗНАЧЕНИЕ
ТРУБЫ ПО API |
ТИП
ТА-35, г/п 35 тонн, под штропа 1.1/4"-1.3/4" |
ТИП
ТА-65, г/п 65 тонн, под штропа 1.1/4"-2.3/4" |
ТИП
ТА-100, г/п 100тонн, под штропа 1.1/4"-2.3/4" |
ТИП ТА-150, г/п 150 тонн, под штропа 1.1/4"-3.1/2" |
||||
| НОМЕР
ЧЕРТЕЖА |
ВЕС,
ФУНТ./КГ. |
НОМЕР
ЧЕРТЕЖА |
ВЕС,
ФУНТ./КГ. |
НОМЕР
ЧЕРТЕЖА |
ВЕС,
ФУНТ./КГ. |
НОМЕР
ЧЕРТЕЖА |
ВЕС,
ФУНТ./КГ. |
||
| 27 |
For
1.050" Plain Tubing |
32387-150 |
35.5
/ 16 |
- |
- |
- |
- |
- |
- |
| For
1.050" Upset Tubing |
32387-151 |
35.5
/ 16 |
- |
- |
- |
- |
- |
- |
|
| 33 |
For
1.315" Plain Tubing |
32387-152 |
39
/ 18 |
- |
- |
- |
- |
- |
- |
| For
1.315" Upset Tubing |
32387-153 |
39
/ 18 |
- |
- |
- |
- |
- |
- |
|
| 42
|
For
1.66" Plain Tubing |
32387-154 |
38
/ 17 |
- |
- |
- |
- |
- |
- |
|
For 1.66" Upset Tubing |
32387-155 |
38
/ 17 |
- |
- |
- |
- |
- |
- |
|
| 48
|
For
1.9" Plain Tubing |
32387-156 |
38
/ 17 |
32385-156 |
64.5
/ 29 |
- |
- |
- |
- |
| For 1.9" Upset Tubing | 32387-157 |
38
/ 17 |
32385-157 |
64.5
/ 29 |
- |
- |
- |
- |
|
| 60
|
For 2 3/8" Plain Tubing | 32387-158 |
37
/ 16.8 |
32385-158 |
64
/ 29 |
- |
- |
- |
- |
| For 2 3/8" Upset Tubing | 32387-159 |
37
/ 16.8 |
32385-159 |
63
/ 28.6 |
- |
- |
- |
- |
|
| For 2 3/8" IUDP Having API Reg or FH Tool Joint | 32387-109 |
37
/ 16.8 |
32385-109 |
63
/ 28.6 |
- |
- |
- |
- |
|
| For 2 3/8" EUDP Having API IF Tool Joint | 32387-115 |
37
/ 16.8 |
32385-115 |
63
/ 28.6 |
- |
- |
- |
- |
|
| 73
|
For 2 7/8" Plain Tubing | 32387-160 |
36.5
/ 16.6 |
32385-160 |
62
/ 28 |
32383-160 |
99
/ 45 |
- |
- |
| For 2 7/8" Upset Tubing | 32387-161 |
36.5
/ 16.6 |
32385-161 |
62
/ 28 |
32383-161 |
99
/ 45 |
- |
- |
|
| For 2 7/8" IUDP Having API Reg or FH Tool Joint | 32387-108 |
36.5
/ 16.6 |
32385-108 |
62
/ 28 |
32383-108 |
99
/ 45 |
- |
- |
|
| For 2 7/8" EUDP Having API IF Tool Joint | 32387-101 |
36.5
/ 16.6 |
32385-101 |
62
/ 28 |
32383-101 |
99
/ 45 |
- |
- |
|
|
89
|
For 3 1/2" IDUP Having API Reg, FH, or X Hole Tool Joint | - |
- |
32386-102 |
83
/ 38 |
32384-102 |
158
/ 72 |
- |
- |
| For 3 1/2" EUDP Having API IF Tool Joint | - |
- |
32386-103 |
83
/ 38 |
32384-103 |
157
/ 71 |
- |
- |
|
| For 3 1/2" Plain Tubing | - |
- |
32386-162 |
83
/ 38 |
32384-162 |
158
/ 72 |
- |
- |
|
| For 3 1/2" Upset Tubing | - |
- |
32386-163 |
83
/ 38 |
32384-163 |
158
/ 72 |
- |
- |
|
| 102
|
For 4" Plain Tubing | - |
- |
32386-164 |
82
/ 37.3 |
32384-164 |
157
/ 71 |
- |
- |
| For 4" Upset Tubing | - |
- |
32386-165 |
82
/ 37.3 |
32384-165 |
157
/ 71 |
- |
- |
|
| For
4" IUDP Having API Reg, FH, or X Hole Tool Joint |
- |
- |
32386-104 |
82
/ 37.3 |
32384-104 |
157
/ 71 |
- |
- |
|
| For 4" EUDP Having API IF Tool Joint | - |
- |
32386-105 |
82
/ 37.3 |
32384-105 |
157
/ 71 |
- |
- |
|
| 114
|
For 4 1/2" Plain Tubing and 4 ?" Casing | - |
- |
32386-129 |
81
/ 36.8 |
32384-129 |
156
/ 70.9 |
- |
- |
| For
4 1/2" Upset Tubing |
- |
- |
32386-167 |
81
/ 36.8 |
32384-167 |
156
/ 70.9 |
- |
- |
|
| For
4 1/2" IUDP Having API Reg, FH or X Hole Tool Joint |
- |
- |
- |
- |
- |
- |
- |
- |
|
| 140
|
For 5 1/2" IUDP Having API Reg or FH Tool Joint | - |
- |
- |
- |
29960-107 |
- |
32754-107 |
430 / 196 |
| For 5 1/2" Casing | - |
- |
- |
- |
29960-132 |
- |
32754-132 |
430
/ 196 |
|
| 168 |
For 6 5/8" Casing | - |
- |
- |
- |
29960-135 |
- |
32754-165 |
430
/ 196 |
| 178 |
For 7 " Casing | - |
- |
- |
- |
29960-136 |
- |
32754-136 |
430
/ 196 |
| 194 |
For 7 5/8" Casing | - |
- |
- |
- |
29960-137 |
- |
32754-137 |
430
/ 196 |
| 219 |
For 8 5/8" Casing | - |
- |
- |
- |
29960-139 |
- |
32754-139 |
430
/ 196 |
